8ND400

8″Mid-Range Speaker
  • 8Ω nominal impedance
  • 6.2Ω minimum impedance
  • 180W RMS capacity
  • 96 dB sensitivity
  • 89-5000 Hz response
  • 50mm(2in) inside-outside voice coil

8ND400 is calm and precise, not afraid of high–energy drive, and releases full power. Make every note clear , even at high speeds, it is still layered. Covering the most sensitive mid-frequency band of the human ear to music, it truly restores the texture, and shows the details of the sound field. Improve heat dissipation efficiency, enhance system stability, and still operate at high power for a long time. It‘s not just about hearing, it‘s a resonant journey through speed and melody.

  • GENERAL SPECIFICATIONS
  • THIELE-SMALL PARAMETERS
  • EXTRA INFO
Nominal Diameter8/200 in/mm
MAX Power360 Watts
RMS Power180 Watts
Impedance8 Ohm
Resonance Frequency89 Hz
Frequency Response89-5000 Hz
Sensitivity(1W/1m)96 dB
Voice Coil Diameter2.0”/50mm
Voice Coil MaterialGSV
MagnetNeodymium
FS89 Hz
RE6.2 ohm
Qms3.8
Qes0.25
Qts0.24
BL18 T/m
MMS24 grams
Xmax3.8 mm
Sd214 cm²
Efficiency2.2 %
Overall Diameter8.27/210 in/mm
Bolt Circle Diameter7.76/197 in/mm
Baffle cutout Diameter7.09/180 in/mm
Depth7.68/195 in/mm
Net Weight3 kgs
Shipping Weight3.4 kgs
Shipping Box23.5X23.5X14cm

Highlights

  • 8”Inside/Out GSV voice coil wounded for hi-temp performance
  • 180 watts continuous power rating makes high acoustical output
  • Sleek look, smooth figure
  • 96dB sensitivity, Superior voice reproduction performance.
  • Powerful sound , high fidelity response

Crumpled paper cone with fiber offers efficient sound performance.
Carefully tuned crossovers provide sound better suited to Eastern listening.
Enhanced bass control with precise acoustic algorithms.
Digital audio processing delivers 3D surround and high-power output.
Hi-Fi signal processing makes tones transparent and detailed.
Deep, powerful bass with realistic, elastic drum sounds.
Clear vocals and rich bass for an immersive music experience.
