CX0827
8″Coaxial Speaker
- 4Ω nominal impedance
- 3.6Ω minimum impedance
- 240W MAX capacity
- 120W RMS capacity
- 92/97 dB sensitivity
- 110-20K Hz response
- 38mm(1.5in) inside-outside voice coil/25mm(1in) voice coil
CX0827 infuses the journey with 3D, immersive sound with a real and dynamic aural soul. Whether it’s surging low frequency or clear vocals, it can easily control. Efficiently driven, and dynamic, so that every song is full of detail and tension. Excellent thermal stability and response speed ensure that it is stable and clear under high-intensity playback without distortion. With good system compatibility, it is ideal for original system upgrades or sound quality improvements.
- GENERAL SPECIFICATIONS
- DRIVER SPECIFICATIONS
- THIELE-SMALL PARAMETERS
- EXTRA INFO
| Nominal Chassis Diameter | 6.5/165 in/mm |
| MAX Power | 240Watts |
| RMS Power | 120 Watts |
| Impedance | 4 Ohm |
| Resonance Frequency | 110 |
| Frequency Response | 110-4K Hz |
| Sensitivity(1W/1m) | 92 dB |
| Voice Coil Diameter | 1.5”/38mm |
| Voice Coil Material | KEI |
| Magnet | 20 Oz |
| Impedance | 4 Ohm |
| Frequency Response | 3K-20K Hz |
| Sensitivity(1W/1m) | 97 dB |
| Voice Coil Diameter | 1”/25mm |
| Winding material | CCAW |
| Diaphragm material | Titanium |
| FS | 110 Hz |
| RE | 3.6 ohm |
| Qms | 7.7 |
| Qes | 0.93 |
| Qts | 0.83 |
| BL | 6.6 T/m |
| MMS | 17 grams |
| Sd | 214 cm² |
| Efficiency | 1.0 % |
| Overall Diameter | 8/210 in/mm |
| Baffle cutout Diameter | 7.6/195 in/mm |
| Depth | 3.3/85 in/mm |
| Net Weight | 1.85 kgs |
| Shipping Weight | 2.25 kgs |
| Shipping Box | 23.5X23.5X13.5cm |
Highlights
- 1.5”Inside/Out KEI voice coil and 1” CCAW voice coil wounded for hi-temp performance
- 120watts continuous program power rating makes high acoustical output
- Sleek look, smooth figure
- 92dB sensitivity, Superior voice reproduction performance.
- Powerful sound , high fidelity response
