MD8C
8″Mid-Range Speaker
- 4Ω nominal impedance
- 3.6Ω minimum impedance
- 80W MAX capacity
- 40W RMS capacity
- 90 dB sensitivity
- 79-6500 Hz response
- 38mm(1.5in) inside-outside voice coil
MD8C is expertly and finely tuned to awaken every listening experience. The system is highly compatible, providing stable and abundant energy support, so that the sound field performance has a sense of power. Accurately restore the texture, presenting a transparent and full timbre level and ensure the stability of long-term high-intensity playback. From the details to the dynamic impact, it‘s a perfect combination of acoustic precision and emotional resonance.
- GENERAL SPECIFICATIONS
- THIELE-SMALL PARAMETERS
- EXTRA INFO
| Nominal Diameter | 8/210 in/mm |
| MAX Power | 80 Watts |
| RMS Power | 40 Watts |
| Impedance | 4 Ohm |
| Resonance Frequency | 79 Hz |
| Frequency Response | 79-6500 Hz |
| Sensitivity(1W/1m) | 90 dB |
| Voice Coil Diameter | 1.5”/38mm |
| Voice Coil Material | KSV |
| Magnet | 20 Oz |
| FS | 79 Hz |
| RE | 3.6 ohm |
| Qms | 1.5 |
| Qes | 0.9 |
| Qts | 0.8 |
| BL | 6 T/m |
| MMS | 18 grams |
| Xmax | 2 mm |
| Sd | 214 cm² |
| Efficiency | 0.7 % |
| Overall Diameter | 8/210 in/mm |
| Bolt Circle Diameter | 7.8/198 in/mm |
| Baffle cutout Diameter | 7.2/184 in/mm |
| Depth | 2.7/70 in/mm |
| Net Weight | 1.8 kgs |
| Shipping Weight | 2 kgs |
| Shipping Box | 23.5X23.5X13.5cm |
Highlights
- 1.5”Inside/Out KSV voice coil wounded for hi-temp performance
- 40watts continuous power rating makes high acoustical output
- Sleek look, smooth figure
- 90dB sensitivity, Superior voice reproduction performance.
- Powerful sound , high fidelity response
Crumpled paper cone with fiber offers efficient sound performance.
Carefully tuned crossovers provide sound better suited to Eastern listening.
Digital audio processing delivers 3D surround and high-power output.
Hi-Fi signal processing makes tones transparent and detailed.
Clear vocals and rich bass for an immersive music experience.
