MD8E

8″Mid-Range Speaker
  • 4Ω nominal impedance
  • 3.6Ω minimum impedance
  • 180W RMS capacity
  • 92 dB sensitivity
  • 79-5000 Hz response
  • 38.6mm(1.5in) inside-outside voice coil

MD8E has flexible matching and smooth signal transmission. Strong output, stable response to highly dynamic music impact, efficient sound performance, fast response, rich details. Natural and transparent timbre, clear layers, vivid reproduction. Strong thermal conductivity and power bearing capacity ensure the speaker is stable and reliable under high-intensity operation. It is an indispensable midrange in the car sound field, making it an expressive car audio system.

  • GENERAL SPECIFICATIONS
  • THIELE-SMALL PARAMETERS
  • EXTRA INFO
Nominal Diameter8/210 in/mm
MAX Power360 Watts
RMS Power180 Watts
Impedance4 Ohm
Resonance Frequency79 Hz
Frequency Response79-5000 Hz
Sensitivity(1W/1m)83 dB
Voice Coil Diameter1.5”/38.6mm
Voice Coil MaterialKEI
Magnet20 Oz
FS79 Hz
RE3.6 ohm
Qms15
Qes0.9
Qts0.88
BL5.8 T/m
MMS18 grams
Xmax2.2mm
Sd214 cm²
Efficiency0.7 %
Overall Diameter8/210 in/mm
Bolt Circle Diameter7.8/198 in/mm
Baffle cutout Diameter7.1/181 in/mm
Depth3.3/84 in/mm
Net Weight2 kgs
Shipping Weight2.8 kgs
Shipping Box23.5X23.5X13.5cm

Highlights

  • 1.5”Inside/Out KEI voice coil wounded for hi-temp performance
  • 180watts continuous power rating makes high acoustical output
  • Sleek look, smooth figure
  • 92dB sensitivity, Superior voice reproduction performance.
  • Powerful sound , high fidelity response

Crumpled paper cone with fiber offers efficient sound performance.
Carefully tuned crossovers provide sound better suited to Eastern listening.
Digital audio processing delivers 3D surround and high-power output.
Hi-Fi signal processing makes tones transparent and detailed.
Clear vocals and rich bass for an immersive music experience.
