PPS4-6

6.5” Mid-Range Speaker

  • 4Ω nominal impedance
  • 3.6Ω minimum impedance
  • 60W RMS capacity
  • 92 dB sensitivity
  • 173-18000 Hz response
  • 38.6mm(1.5in) inside-outside voice coil

PPS4-6 This midrange speaker is built to restore the original sound of music, delivering rich and nuanced midrange details with a clean, natural tone for truly comfortable listening. Its precision structure guarantees accurate sound with transparent vocals and smooth instrument dynamics. The efficient magnetic circuit enhances sound clarity and layering, providing warm, soft midrange and exceptional resolution.

  • GENERAL SPECIFICATIONS
  • THIELE SMALL PARAMETERS
  • EXTRA INFO
Nominal Chassis Diameter6.5/165 in/mm
MAX Power300 Watts
RMS Power150 Watts
Impedance4 0hm
Resonance Frequency124 Hz
Frequency Response124-13000 Hz
Sensitivity(1W/1m)94 dB
Voice Coil Diameter1.5” / 38.6mm
Winding materialCCAW
Magnet34 Oz
120X45X20 mm



FS124 Hz
Vas3.86 dm3
RE3.2 ohm
Qms10.7
Qes0.56
Qts0.53
BL6.9 T/m
MMS10.5 grams
Xmax3.5 mm
Sd132 cm²
Efficiency1.25 %
EBP221



Overall Diameter6.7/170 in/mm
Bolt Cirde Diameter6.2/158 in/mm
Baffle cutout Diameter5.7/145 in/mm
Depth2.7/70 in/mm
Net Weight2.1 kgs
Shipping Weight2.3 kgs
Shipping Box18.5X18.5X10.5 cm
